Product






Basic



  • Color:  Asteroid Black



  • Ingress Protection Rating: IP68



  • Operating System: Funtouch OS 14



  • Android Version: Android 14







Price



*







Platform



Processor



Dimensity 9300







CPU Core Count



8

Process Node



4 nm

CPU Clock Speed



3.25 GHz x 1 + 2.85 GHz x 3 + 2.0 GHz x 4






Storage



RAM & ROM



16 GB + 512 GB



  RAM Type



LPDDR5X

ROM Type



UFS 4.0





Expandable RAM Capacity

16 GB




Battery



Battery



This product is designed with dual-cell series connection:
Typical capacity: 2700 mAh (7.78V), equivalent to 5400 mAh (3.89V).
Typical energy: 21.01 Wh
Rated capacity: 2630 mAh (7.78V), equivalent to 5260 mAh (3.89V).
Rated energy: 20.47 Wh







Charging Power



100W FlashCharge, 50W Wireless FlashCharge





Battery Type



Li-ion battery






Design



Dimensions



16.405 x 7.528 x 0.891 cm (164.05 x 75.28 x 8.91 mm)







Weight



225g





Back Cover Material



Glass





Fingerprint Sensor Type



In-display optical fingerprint sensor






Display



Size



17.22 cm (6.78 inches)







Resolution



2800 x 1260 (FHD+)





Type



AMOLED





Touch Screen



Capacitive multi-touch





Refresh Rate



Up to 120 Hz





Local Peak Brightness



3000 nits





Color Gamut



100% DCI-P3





Color Saturation



105% NTSC





Pixel Density



452 PPI





Light-Emitting Material



VM7






Network



Card Slot



2 nano SIMs (SIM1 + SIM2) or 1 nano SIM + eSIM







Standby Mode



Dual SIM Dual Standby (DSDS)





2G GSM



850/900/1800/1900 MHz





3G WCDMA



B1/B2/B4/B5/B8





4G FDD-LTE



B1/B2/B3/B4/B5/B7/B8/B12/B17/B18/B19/B20/B26/B28/B32/B66



4G TDD-LTE



B38/B39/B40/B41/B42



5G



n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n66/n75/n77/n78/n79





Digital Cameras



Camera



Front 32 MP / Rear 50 MP + 50 MP + 50 MP





Aperture



Front f/2.0 (32 MP), Rear f/1.75 (50 MP) + f/2.0 (50 MP) + f/2.5 (50 MP)



Flash



Rear flash



Scene Modes



Snapshot, Night, Portrait, Photo, Video, High Resolution, Pano, Ultra HD Document, Slo-mo, Long Exposure, Time-Lapse, Supermoon, Astro, Landsc. & Archit., Pro, Food, Live Photo, Cinematic Portrait






media



Audio Playback



AAC, WAV, MP3, MIDI, VORBIS, APE, FLAC







Video Playback



MP4, 3GP, AVI, FLV, MKV, WEBM, TS, ASF





Video recording



MP4





Voice Recording



Supported






Connectivity



Wi-Fi



Wi-Fi 6, Wi-Fi 7, WLAN 2.4 GHz/5 GHz/6 GHz, Wi-Fi Display, 2 x 2 MIMO, MU-MIMO







Bluetooth



Bluetooth 5.4





USB



USB Type-C, USB 3.2 Gen1





GPS



Supported





OTG



Supported





Location



GPS, BeiDou, GLONASS, Galileo, QZSS, NavIC, A-GPS, cellular positioning, Wi-Fi positioning, geofencing







Sensors



Fingerprint



Supported







Accelerometer



Supported





Ambient light sensor



Supported





Proximity Sensor



Supported





E-compass



Supported





Motor



Supported





Gyroscope sensor



Supported






In the box



Documentation


Model


Quick Start Guide


USB Cable


Charger


Eject Tool


Phone Case


Protective Film (applied)


Warranty Card








SAR Values



Head (1 g)



0.996 W/kg







Body (1 g)



0.833 W/kg (15 mm distance)






Additional Information



Country of Origin



India







Name and Address of the Manufacturer



vivo Mobile India Private Limited TEC-1, TEC-2 & ONE C, WORLD TRADE CENTRE NOIDA, PLOT NO: TZ-13A, TECHZONE (I.T. PARK) GREATER NOIDA: 201308, UTTAR PRADESH, INDIAUttar Pradesh,India-201308





Generic Name



Mobile Phone





Net quantity



1 Unit
